SIP Methods Explained: INVITE, REGISTER, BYE, ACK & More

Dive into the core SIP methods like INVITE, REGISTER, BYE, and ACK. Learn their purpose, how they work, common pitfalls, and real-world examples to master VoIP communication.

Product Team
Product Team
•2 min read
Illustration for SIP Methods Explained: INVITE, REGISTER, BYE, ACK & More

Demystifying SIP Methods: The Core of VoIP Communication

Session Initiation Protocol (SIP) is the signaling backbone of modern Voice over IP (VoIP) and real-time communication. At its heart are SIP methods, special request types that tell a SIP server what action a client wants to perform. These methods define the different functions in a SIP call, from initiating a conversation to ending it, managing presence, and transferring calls.

Understanding SIP methods is crucial for anyone working with VoIP – whether you're a junior telecom engineer troubleshooting a call, a developer integrating SIP into an application, or an operations professional monitoring network traffic. They solve the fundamental problem of how to establish, maintain, and terminate multimedia sessions over an IP network, providing a standardized language for SIP endpoints to communicate.

How SIP Methods Work

SIP communication operates on a request-response model. A client (User Agent Client or UAC) sends a request containing a specific method, and a server (User Agent Server or UAS, or a Proxy Server) processes it and sends back a numerical response code (e.g., 200 OK for success, 404 Not Found for failure). Each method triggers a distinct behavior, orchestrating the complex dance of real-time communication.

Let's dive into the most common and critical SIP methods:

1. INVITE: Starting a Conversation

Definition: The INVITE method is used to initiate a session with another user agent. It proposes a communication session, typically a phone call, by inviting a user to participate.

Why it exists: It solves the problem of how to alert a user and negotiate the parameters for a real-time communication session (like a voice call or video conference) before media exchange begins. Without INVITE, there's no way to establish a connection.

How it works:

  1. The caller's User Agent Client (UAC) sends an INVITE request to the callee, often via a SIP Proxy Server.
  2. The callee's User Agent Server (UAS) receives the INVITE and typically sends a provisional response (e.g., 100 Trying, 180 Ringing) to indicate progress.
  3. If the callee accepts the call, the UAS sends a 200 OK final response.
  4. The UAC confirms receipt of the 200 OK with an ACK request, and the session is established. Media (RTP) then begins flowing.

Example:

INVITE sip:[email protected] SIP/2.0
Via: SIP/2.0/UDP 192.168.1.10:5060;branch=z9hG4bK-somenumber
From: Alice <sip:[email protected]>;tag=abc
To: Bob <sip:[email protected]>
Call-ID: [email protected]
CSeq: 1 INVITE
Contact: <sip:[email protected]>
Content-Type: application/sdp
Content-Length: 150

v=0
o=alice 2890844526 2890844526 IN IP4 192.168.1.10
s=-
c=IN IP4 192.168.1.10
t=0 0
m=audio 5000 RTP/AVP 0
a=rtpmap:0 PCMU/8000

Common mistakes: Missing SDP (Session Description Protocol) in the INVITE, incompatible codecs, network connectivity issues (firewalls), or issues with the SIP INVITE handshake itself.

Related terms: SDP, RTP, 200 OK, ACK, Provisional Responses.

2. REGISTER: Announcing Your Presence

Definition: The REGISTER method is used by a user agent to inform a SIP Registrar server of its current location (IP address and port) so that incoming calls can be routed correctly.

Why it exists: It solves the

Tags:sipvoiptelecommethodsprotocol
